TopDiag P200 Car Circuit Intelligent Analyzer Diagnostic Instrument

1. Supported languages: English, Simplified Chinese, Traditional Chinese, French, Spanish, Thai, Italian, Indonesian, Vietnamese, Russian, Malay, Portuguese, Arabic, German
2. Component activation function, which can effectively realize the on-off and activation test of various parts of the car, such as car bulbs, motors, ECU and other components,
3. Three activation modes: instant activation, locking activation, pulse activation
4. The multimeter function includes commonly used parameters, which can quickly test the DC voltage, resistance, diode, current and frequency in the circuit system.
5. Parameters:
Screen size: 2.4 inch TFT true color display
Working temperature: 0-60 degrees Celsius
Storage temperature: 40-70 degrees Celsius
External power supply: powered by 12 or 24V battery
Working voltage: 9-30V
Measuring voltage: 0.1-100V
Resistance measurement range: 1-200K Ohm
Current measurement range: 0-18A
Continuous current: 18A max
